FOX 500 Tx/Rx • Reference Information

Reference Information, cont’d

FOX 500 Tx/Rx • Reference Information

A-6

A-7

Serial control pin configurations

Captive screw connectors: 1 = Tx, 2 = Rx,
3 = GND
Mini stereo jack: tip = Tx, ring = Rx,
sleeve = GND

Program control ............................. Extron’s control/configuration program

for Windows

®

Extron’s Simple Instruction Set (SIS

)

General

Power .............................................. 100 VAC to 240 VAC, 50-60 Hz, 11 watts,

internal

Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /

10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing

Cooling ........................................... Convection, vents on top and sides
Mounting

Rack mount ........................ Yes, with optional rack shelf kit
Furniture mount ................ Yes, with optional under desk mounting

kit

Enclosure type ............................... Metal
Enclosure dimensions ................... 1.7" H x 8.7" W x 9.5" D

(1U high, half rack wide)
(4.3 cm H x 22.1 cm W x 24.1 cm D)
(Depth excludes connectors and knobs.)

Product weight .............................. 2.3 lbs (1.0 kg) per unit,

4.6 lbs (2.1 kg) per pair

Shipping weight ............................ 4 lbs (2 kg) per unit, 8 lbs (4 kg) per pair
Vibration ......................................... ISTA 1A in carton

(International Safe Transit Association)

Regulatory compliance

Safety ................................... CE, CUL, FDA Class 1, UL
EMI/EMC .......................... CE, C-tick, FCC Class A, ICES, VCCI,

MTBF ............................................... 30,000 hours
Warranty ......................................... 3 years parts and labor

N

All nominal levels are at ±10%.

N

Specifications are subject to change without notice.

FOX 500 DVI Specifications

N

The FOX 500 DVI consists of a transmitter (FOX 500 DVI Tx)
and a receiver (FOX 500 DVI Rx) with one or two fiber optic
cables linking the two units. They are available in singlemode or
multimode versions.

N

The analog audio signal(s) is (are) digitized in the transmitter,
sent through the fiber cable, and converted back to analog audio
in the receiver.

N

These transceivers are class 1 laser products. They meet the
safety regulations of IEC-60825, FDA 21, CFR 1040.10, and
FDA 21 CFR 1040.11.

Optical fiber interconnection between transmitter and

receiver

Number/type ................................ 1 or 2 fiber optic

N

Only one fiber is required to transmit video, audio, and
unidirectional data. A second fiber is required to transmit
return data for bidirectional control/communication.

Connectors ..................................... 2 LC connectors
Operating distance

Singlemode ......................... 30 km (18.75 miles) with singlemode (SM)

cables with a FOX 500 DVI SM

Multimode .......................... 300 m (985') with 62.5 µm multimode

(MM) cables with a FOX 500 DVI MM
1 km (3280') with 50 µm multimode (MM)
cables with a FOX 500 DVI MM
2 km (6561') with 50 µm 2000 MHz
bandwidth laser optimized multimode
cable with a FOX 500 DVI MM

N

Operating distance is approximate. These are typical maximum
distances that may vary depending on factors such as fiber type,
fiber bandwidth, connector splicing, losses, modal or chromatic
dispersion, environmental factors, and kinks.

Nominal peak wavelength........... 850 nm for FOX 500 DVI MM,

1310 nm for FOX 500 DVI SM

Data rate ......................................... 4.25 Gbps
