Page 30: Remote contr ol, cont’d

FOX 500 Tx/Rx • Remote Contr
ol
Remote Contr
ol, cont’d
4-10
FOX 500 Tx/Rx • Remote Contr
ol
4-11
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Pixel phase
N
When the controlling PC is connected to the receiver, the FOX 500 can perform this command only if the fiber 2 cable is connected. The unit
returns the E14 error if the fiber 2 cable is not connected.
Set a pixel phase value
X^
U
Phs
X^]
Set the pixel phase value to
X^
.
Example:
10U
Phs10
]
Set the pixel phase value to 10.
Increment pixel phase
+U
Phs
X^]
Increase pixel phase value by 1..
Decrement pixel phase
-U
Phs
X^]
Decrease pixel phase value by 1.
Show pixel phase
U
X^]
Total pixels
N
When the controlling PC is connected to the receiver, the FOX 500 can perform this command only if the fiber 2 cable is connected. The unit
returns the E14 error if fiber 2 is not connected.
Set a total pixel value
11*
X&
#
Tpx
X&]
Set the total pixels to a specific value.
Example:
11*1555#
Tpx1555
]
Set the total pixel value to 1555.
Increment total pixel value
+11#
Tpx
X&]
Increase total pixel value by 1 pixel.
Decrement total pixel value
-11#
Tpx
X&]
Decrease total pixel value by 1 pixel.
Show total pixel value
11#
Tpx
X&]
List sync frequency
View input frequency
1LS
X*
,
X*]
List the input frequency as
X*
kHz (horizontal) and
X*
Hz (vertical.
Command/response table for SIS commands (continued)
Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional description
Memory presets
Save preset
X(,
Spr
X(]
Command code is a comma.
Recall preset
X(.
Rpr
X(]
Command code is a period.
Audio input gain and attenuation
N
The set gain (G) and attenuation (g) commands are case sensitive.
N
When the controlling PC is connected to the receiver, the FOX 500 can perform this command only if the fiber 2 cable is connected. The unit
returns the E14 error if fiber 2 is not connected.
Set input audio gain to +dB
value
X1)
G
Aud
X1@]
Example:
2G
Aud+02.0
]
Set the input audio gain to +2 dB.
Set input audio attenuation
to -dB value
X1!
g
Aud
X1@]
Increment level
+G
Aud
X1@]
Increase audio level by 1.0 dB.
Example:
+G
Aud+03
]
Increment the audio input level from +2 dB to +3 dB.
Decrement level
-G
Aud
X1@]
Decrease the audio level by 1.0 dB.
Example:
-G
Aud-09
]
Decrement audio input level from -08 dB to -9 dB.
Show input gain
G
X1@]
Command/response table for SIS commands (continued)
N
X^
= Pixel phase
0 to 31
X&
= Total pixels
± 255 of the default value
X*
= Sync frequency
xxx.xx (frequency in kHz [H] or Hz [V])
N
X(
= Memory preset number
1 to 30
X1)
= Audio gain adjustment range
0 to 10
X1!
= Audio attenuation adjustment range
0 to 18
X1@
= Audio level adjustment range
-18.0 to +10.0- (in 1.0 dB steps)
