FOX 500 Tx/Rx • Remote Contr

ol

Remote Contr

ol, cont’d

4-12

FOX 500 Tx/Rx • Remote Contr

ol

4-13

Command

ASCII Command

(host to unit)

Response

(unit to host)

Additional description

Audio output level

Set to consumer line level

40*0#

Lvl0

]

Set the transmitter's audio output to the consumer
(–10 dBV) line level.

Set to professional line level

40*1#

Lvl1

]

Set the transmitter's audio output to the professional
(+4 dBu) line level.

Show the audio output line
level

40#

X1#]

0 = consumer, 1 = professional.

Audio mute

Mute the audio

1Z

Amt1

]

Silence the receiver's audio output.

Unmute the audio

0Z

Amt0

]

The receiver outputs audio.

Show audio mute status

Z

X!]

Audio output mute status is

X!

(0 = unmuted, 1 =

muted).

Auto memory

Disable auto memory

55*0#


]

Enable auto memory

55*1#


]

Show auto memory status

55#

X!]

Auto image

Trigger auto image

55*2#


]

Command/response table for SIS commands (continued)

Command/response table for SIS commands (continued)

Command

ASCII Command

(host to unit)

Response

(unit to host)

Additional description

Front panel lock (Executive mode)

Lock the front panel

1X

Exe1

]

Unlock the front panel

0X

Exe0

]

Show the panel lock status

X

X!]

Test pattern

N

You must have a video input connected and fiber cable Optical 1 connected between the transmitter and receiver for the receiver to output a

selected test pattern.

The test pattern will turn off if the input signal rate is changed or disconnected or if power is removed.

Output Color Bars

1J

Tst1

]

Set the receiver to output the Color Bars test pattern.

Output grayscale

2j

Tst2

]

Set the receiver to output the grayscale test pattern.

Output alt. pixels

3J

Tst3

]

Set the receiver to output the alternating pixels test
pattern.

Test pattern off

0J

Tst0

]

Set the receiver to output the input video (no test pattern
selected)

Show test pattern status

J

X1$]

N

X!

= Mute status

0 = off

1 = on

X1#

= Audio output level

0 = consumer

1 = professional

N

X!

= Lock status

0 = unlocked

1 = locked

X1$

= Test pattern

0 = none

1 = Color Bars

2 = grayscale

3 = alternating pixels
