Bell & Gossett S14333 Technologic 5500 Series ZoneSav Controller User Manual
Page 36
36
CPU & OPERATOR
INTERFACE
BACNET IP PORT
(OPTIONAL)
RS COMMUNICATION
PORT SLOT 1
(OPTIONAL)
ANALOG
OUTPUT
SLOT 3
(OPTIONAL)
ANALOG
INPUT
SLOT 4
(OPTIONAL)
RACK O
DIGITAL INPUT
RACK O
DIGITAL OUTPUTS
CUSTOMER
CONNECTIONS
HMS AB7009
(OPTIONAL)
24VDC
POWER
SUPPLY
ANALOG
OUTPUT
SLOT 6
ANALOG
INPUT
SLOT 5
RACK 0
RACK 1
Drawing 2: Technologic 5500 Series ZoneSav (Front View Door Open)
Drawing 3: Technologic 5500 Series ZoneSav Field Connection Diagram
