Appendix E - BACnet Protocol Implementation
Conformance Statement for BACnet MS/TP
BACnet Protocol Implementation Conformance Statement
Date: 9/13/06
Vendor Name: ITT Bell & Gossett
Product Name: Technologic 5500 Series ZoneSav Valve Controller
Product Model Number: N/A
Applications Software Version: 1.71 or above Firmware Revision: N/A BACnet Protocol Revision: 2.0
Product Description: The ZoneSav is a valve controller for HVAC. It operates either as a stand-alone controller or as part of a
building-wide integrated system. The BACnet communication interface will provide communication between the ZoneSav and
the BACnet system residing on EIA-485 media.
BACnet Standardized Device Profile (Annex L): BACnet Application Specific Controller (B-ASC)
List all BACnet Interoperability Building Blocks Supported (Annex K): DS-RP-B, DS-RPM-B, DS-WP-B, DS-WPM-B, DM-TS-B
Segmentation Capability: None
Standard Application Services Supported:
Application Service
Initiate Requests Executes Requests
Read Property
No
Yes
Read Property Multiple
No
Yes
Write Property
No
Yes
Write Property Multiple
No
Yes
Time Synchronization
No
Yes
Who-Has
No
Yes
I-Have
Yes
Yes
Who-Is
No
Yes
I-Am
Yes
Yes
Standard Object Types Supported:
Object Type
Dynamically Creatable
Dynamically Deletable Optional Properties Supported
Writable Properties
Analog Input
No
No
None
Analog Output
No
No
None
Analog Value
No
No
None
Present Value
Binary Input
No
No
None
Binary Output
No
No
None
Binary Value
No
No
None
Present Value
Data Link Layer Options:
२ BACnet IP, (Annex J)
२ BACnet IP, (Annex J), Foreign Device
२ ISO 8802-3, Ethernet (Clause 7)
२ ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
२ ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____________
२ MS/TP master (Clause 9), baud rate(s): ____________
२ MS/TP slave (Clause 9), baud rate(s): 9600, 19200, 38400
२ Point-To-Point, EIA 232 (Clause 10), baud rate(s): ____________
२ Point-To-Point, modem, (Clause 10), baud rate(s): ____________
२ LonTalk, (Clause 11), medium: __________
२ Other: ____________
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain other
devices.)
२ Yes
२ No
Networking Options:
२ Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
२ Annex H, BACnet Tunneling Router over IP
२ BACnet/IP Broadcast Management Device (BBMD).
२
Does the BBMD support registrations by Foreign Devices?
२ Yes २ No
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
२ ANSI X3.4
२ IBM™/Microsoft™ DBCS
२ ISO 8859-1
२ ISO 10646 (UCS-2)
२ ISO 10646 (UCS-4)
२ JIS C 6226
X
X
X
