6. Inspections and maintenance
6.1 List of inspections
TYPE OF THE
INSPECTION BY WHOM HOW OFTEN WHAT TO DO/CHECK
A. General visual
inspection
-Customer
-Trained technician Every 6-12 months  Check for damages or cracks of the frame,
adapter or arc chute
 Check for missing screws or caps
 Check for damaged labels
 Check for corrosion
 Check for distinct manifestations of flame or
smoke at the frame
 Clean the breaker from dirt and dust
 Clean and degrease the copper terminals
B. General functional
inspection
-Customer
-Trained technician
Every 6-12 months  Manually close and open the breaker to
check the drive and mechanism
 Close the breaker electrically and open by
trip unit(s) releasing, to check controls
C. Inspection of the arc
chute and contact
system
-Customer
-Trained technician
Every 6-12 months
or after:
 high short circuit
opening at >25 kA
 >300 openings at load
current
 >100 openings at over
current load (2-3 x In)
It is recommend to carry
out inspection of contact
system after breaking of
equivalent of 150MA 2 s total
let through energy.
 Check for wear of the arc runners; shall
not exceed 30 % of its cross section
 Check for wear of the pre-arcing contact.
It shall not exceed 2 mm [0.08 in].
 Check for wear of the main contacts at
fixed and flexible sides; shall not exceed
1.5 mm [0.06 in] of its depth.
 Check for wear of the arc chute plates;
check for deposits inside of arc chute, this
area shall be free of deposits.
 Check for wear of protective walls; shall
not exceed 1 mm [0.04 in].
 Check for contact tilt and gaps.
D. Inspection of the
screw/bolt connections
-Customer
-Trained technician
Every 6-12 months
or after every inspection:
 of the arc runners
 of the contacts
 of the arc chute
Check the position of the countersunk screws
in the sidewalls.
Check for tightness or use torque tool (torque
in SI and Imperial units):

M8 ~20 Nm [~ 177 in-lbs]
 M6 ~10 Nm [~ 88 in-lbs]
 M5 ~5 Nm [~ 44 in-lbs]
 M4 ~3 Nm [~ 26 in-lbs]
E. Inspection of the
mechanic components
-GE
-Service technician
Every 5 years
or
After 5.000 openings
 Carry out inspection “B” above
 Check out settings of the main contacts
and auxiliary switch
 Check out main flexband breakage; shall
not exceed 30 % of its cross section
 Check out wear of mini flexband; shall not
exceed 30 % of its cross section
 Clean and degrease UVR latch and quick
latch of the mechanism. Apply dash of
Beacon EP2 grease afterwards.
Required tools:
Cleaning tissue; abrasive paper; manual closing lever; hexagon wrenches SW5, SW6; Torx® wrenches size 30, 40, 45; small and
medium screwdrivers; ratchet with 10 mm hex cap; pliers; tongs.
Dispose of the breakers if required:
Pay attention to the national and local regulations of disposal!
