Electrical circuits – GE Industrial Solutions GERAPID 2508, 4008, 5008, 6008 WITH ARC CHUTE 1X2 User Manual
Page 14
14
Design and specifications are subject to change without notice
S47183De rev.02 2011-03-14
4. Electrical circuits
4.1 Controls layout
Description
Designation
X2
1.Connector: Auxiliary- and control circuits
X3
2.Connector: Auxiliary- and control circuits
X4
3.Connector: Auxiliary contacts HS1...HS5
X5
4.Connector: Auxiliary contacts HS6...HS8
X10
Control board: Voltage converter
X12
Control board: SU control unit
X13
Control board: Shunt trip control unit
X14
Control board: Zero voltage release
X16
Control board: NEKO control unit for ED coil control
X20 UL
interlock
