CHAPTER 2: INSTALL ATION/CONFIGURATION
EP OS MOTOR MANAGEMENT SY STEM – INSTRUCTION MANUAL 2.13
2.2.1.4 Motor Control via WinESG
Similar configuration as above can be done using GE configuration software WinESG. Refer to WinESG
parameterization /control panel on Chapter 5.
2.2.1.5 Motor Control via Profibus Class
1
2.2.1.6 ATEX Configuration
After configuring the switch control via Modbus or WinESG, write telegram B10008 can be
auto-reset is not allowed.
used to control the
ATEX can be done using Modbus RTU master or WinESG configurator tool ONLY (Profibus-DP Class1 CANNOT be used):
Modbus by settings register 111 bit 0 to 1, using Function Code 06.
EntelliPro ES can be configured for use in potentially explosive atmospheres (ATEX). Configuration of EntelliPro ES as
WinESG Configurator - refer to WinESG parameterization typical settings panel in section 5.3.2.8.
contactors. Refer to Chapter 4 for additional information on
Phase Loss cannot be disabled or set as warning. It must be configured as fault only. The Phase Loss time delay is
Certain configuration restrictions are placed when configured as ATEX:
Overload protection cannot be disabled or set as warning. It must be configured as fault only.
Thermal memory cannot be disabled
.
Auto-Reset parameter can be set to manual reset, one auto-reset, two auto-reset and three auto-reset only. Always
ATEX redundancy contactor is made available.
Phase Unbalance time delay is automatically set to 500msec instead of selectable from 1 to 15 seconds.
automatically set to immediate, instead of selectable from 1 to 15 seconds.
Thermistor protection cannot be disabled or set as warning. It must be configured as fault only.
this telegram.
2.2.2 Motor Control Pre-Programmed Configuration
For ease of configuration, EntelliPro ES provides a set of control mode variances that allow easy control of the motor
by different means: Modbus, Profibus Class1, WinESG and Hardwire.
To enable the pre-programmed control configuration, the default configuration must be enabled in the WinESG
parameterization/information panel. To enable the default configuration via Modbus, holding register 62 bit 0 must
be set.
WinESG parameterization/information panel shown in illustration below, can be used to configure the default
configuration parameter.
Six pre-programmed controls variant are available. Following is the configuration of each variant.
NOTE: Control variants 2 and 5 are not applicable to EntelliPro ES3.
