Entellipro es, Parameters cannot be set via the main panel – GE Industrial Solutions EntelliPro ES User Manual
Page 240
2 : Valve 1
COM 1
2 : Valve 1
COM 1
Button to switch into the
parameter screen
Button to switch into the
measurement screen
Button to switch into the
diagnostic screen
Button to switch into the
characteristics screen
Button to switch back to
previous menu
Button to switch to next
selection menu
Button to switch back to
previous menu
Button to switch to previous
screen selection
Button to switch into the
service screen
(not available)
Button to switch into the
EntelliPro CP3 setting screen
CHAPTER 6: ENTELLIPRO CP3 and CP5 APPLICATION
The following two figures show the menu screen selections and descriptions
EPOS MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
6.5
