4.32 EP OS MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
CHAPTER 4: COMMUNICATION
Input
Register
Address
Data
Size
Parameter Name Units Scale Format Note
102 16 bit Fault Type
BIT0 - Overload Failure (Trip)
BIT1 - Phase Loss Failure (Trip)
BIT2 - Gf Failure (Trip) (trip)
BIT3 - Unbalanced Load Failure (Trip)
BIT4 - Thermistor Failure (Trip)
BIT5 - Emergency Stop Failure (Trip)
BIT6 - LimitSwitch Failure (Trip)
BIT7 - SafetyCircuit Failure (Trip)
BIT8 - MainCircuit Failure (Trip)
BIT9 - ControlCircuit Failure (Trip)
BIT10 - SwitchPosition Failure (Trip)
BIT11 - UnderLoadCurrent Failure (Trip)
BIT12 - OverLoadCurrent Failure (Trip)
BIT13 - ExternalSupervision Failure (Trip)
BIT14 - LongStart Failure (Trip)
BIT15 - TypicalSpecific Failure (Trip)
Unsigned Integer “1 means the fault has occurred
To clear the fault refer to FC 04 command 65-80”
103 16 bit Warning Type
BIT0 - OverloadWarning
BIT1 - Phase Loss Warning
BIT2 - GfWarning
BIT3 - UnbalancedLoadWarning
BIT4 - ThermistorWarning
BIT5 - EmergencyStopWarning
BIT6 - LimitSwitchWarning
BIT7 - SafetyCircuitWarning
BIT8 - MainCircuitWarning
BIT9 - ControlCircuitWarning
BIT10 - SwitchPositionWarning
BIT11 - UnderLoadCurrentWarning
BIT12 - OverLoadCurrentWarning
BIT13 - ExternalSupervisionWarning
BIT14 - LongStartWarning
BIT15 - TypicalSpecificWarning
Unsigned Integer “1 means the Alarm has occured
To clear the fault refer to FC 04 command 81-96”
104 16 bit Device Error Type
BIT0 - Free
BIT1 - Free
BIT2 - ParameterError
BIT3 - WatchdogError
BIT4 - Free
BIT5 - Free
BIT6 - NOVRAM/EEPROMError
BIT7 - Reserved
BIT8 - Free
BIT9 - Thermistor hardware
BIT10 - 15 - Free
Unsigned integer “1 means the Device Error has occured
To clear the fault refer to FC 04 command 97-106”
110 16 bit Profibus Slave Address Unsigned Integer
112 16 bit Event Log Index Counter Indicates the most recent event index in the event log.
113 16 bit Counter1 Value
114 16 bit Counter2 Value
115 16 bit Counter3 Value
116 16 bit Counter4 Value
