CHAPTER 4: COMMUNICATION
4.44 EP OS MOTOR MANAGEMENT SYSTEM – INSTRUCTION MANUAL
Size Telegram Name Description Default Bytes Unit Scale
B2734 Additonal Counter (not available on EntelliPro ES Retrofit version) 43
32-bit Contactor 1 Operations Counter 4
32-bit Contactor 2 Operations Counter 4
32-bit Contactor 3 Operations Counter 4
32-bit Contactor 4 Operations Counter 4
16-bit Thermal Overload trips Counter 2
16-bit Thermistor trips Counter 2
16-bit Ground Fault Sum Trip Counter 2
32-bit Hours of non-operation (Motor stopped hours) 4
8-bit Event Log Index Counter 1
16-bit Reserved 4
16-bit Reserved 4
16-bit Reserved 4
16-bit Reserved 4
B4000 9 Debug telegram 4
8 bit Modbus Control Byte1 BEAM 8 7 6 5 4 3 2 1
8 bit M odbus Control Byte2 BEAM 16 15 14 13 12 11 10 9
8 bit Modbus Control Byte 3 B EAM 24 23 22 21 20 19 18 17
8 bit Status Telegram- Byte 4 BAM 32 31 30 29 28 27 26 25
