Galaxy Power System Verification Procedures
5 - 2 Glossary
Issue 3 January 2008
SC Controller Circuit Boards
The following figure shows the location of the Basic and Intelligent
circuit boards in the SC Controller, which are described in the following
pages.
Location of Basic and Intelligent Boards in the SC Controller
BJE Alarm Board
BJF Termination
Fuse Board
BJA Independent Power Board
BJC Rectifier Interface Board
BJB Independent Controller
BJH Intelligent Controller
BJL Modem Board
BJJ Intelligent
Power Board
Options
Slot 4
Options
Slot 3
Options
Slot 2
Options
Slot 5
Modem
BJT Termination Board
Option
