44
GEH-702 Users Manual
Table 29. Communication Parameters: Modbus Function 5
Register Parameter Value Read/Write
101 Save Data Write
103 Save Real Time Clock Registers Write
104 Read Real Time Clock Registers Write
106 Defeat Ground Fault
0 – OFF
1 – ON
Write
108 Trip Breaker 1 – Trip Write
112 Relay 1 state
1 – ON
0 – OFF
Read/Write
113 Relay 2 state
1 – ON
0 – OFF
Read/Write
114 ZSI-Out
1 – ON
0 – OFF
Read/Write
115 Clear Power Demand 1 – Clear Write
116 Clear All Events 1 – Clear Write
117 Clear EEPROM 1 – Clear Write
118 Clear Energy Total 1 – Clear Write
119 Clear All Trip Counters 1 – Clear Write
120 Clear LT Trip Counter 1 – Clear Write
121 Clear All Pickup Counters 1 – Clear Write
122 Clear Short Time Trip Count 1 – Clear Write
123 Clear Instantaneous Trip Count 1 – Clear Write
124 Clear Ground Sum and CT Fault Trip Counts 1 – Clear Write
125 Clear Rating Plug Too Small Count 1 – Clear Write
126 Clear Power Reversal Trip Count 1 – Clear Write
127 Clear Voltage Unbalance Trip Count 1 – Clear Write
128 Clear Under Voltage Trip Count 1 – Clear Write
129 Clear Current unbalance Trip Count 1 – Clear Write
130 Clear Overvoltage trip Count 1 – Clear Write
131 Clear Over Temperature Trip Count 1 – Clear Write
132 Clear ROM CRC fault count 1 – Clear Write
135 Clear Metering Data 1 – Clear Write
143 Trigger Waveform Capture 1 – Clear Write
144 Clear Waveform Capture Data Buffer 1 – Clear Write
145 Clear Preventive Maintenance data 1 – Clear Write
148 Clear STO trip count 1 – Clear Write
149 Clear Comm. trip count 1 – Clear Write
