GE Industrial Solutions Spectra RMS Molded Case - Manual (Page 28)

GEH-702 Users Manual
27
Table 21. Wye Configuration Metering
Function Title (as implemented) Data Presented Notes
Current Metering CURRENT
PHA - 0A
PHB - 0A
PHC - 0A
Each phase current
CURRENT N - 0A Neutral current
Voltage Metering VOLTAGE
L1-N - 0V
L2-N - 0V
L3-N - 0V
Phase to neutral voltages
Power Metering REAL PWR
PHA - 0KW
PHB - 0KW
PHC - 0KW
Real power by phase
REAC PWR
PHA - 0KW
PHB - 0KW
PHC - 0KW
Reactive power by phase
APPR PWR
PHA - 0KVA
PHB - 0KVA
PHC - 0KVA
Apparent power by phase
PWR DMD
PRST – 0KW
PEAK – 0KW
PRST-Peak power during last demand interval
PEAK-Peak power since first power
Energy Metering ENERGY TOTAL–0KWH Total energy usage
Frequency FREQUENCY 60HZ Frequency measurement
Power Factor PWR FACTOR
PHA - 0%
PHB - 0%
PHC - 0%
Power factor by phase
Table 22. Delta Configuration Metering
Function Title (as implemented) Data Presented Notes
Current Metering CURRENT
PHA - 0A
PHB - 0A
PHC - 0A
Each phase current
CURRENT N - 0A Neutral current
Voltage Metering VOLTAGE
L1-L2 - 0V
L2-L3 - 0V
L1-L3 - 0V
Line to line voltages
Power Metering REAL PWR TOTAL– 0KW Total real power
REAC PWR TOTAL– 0KW Total reactive power
APPR PWR TOTAL– 0KVA Total apparent power
PWR DMD
PRST – 0KW
PEAK – 0KW PRST-Peak power during last demand interval
PEAK-Peak power since first power
Energy Metering ENERGY TOTAL– 0KWH Total energy usage
Frequency FREQUENCY 60HZ Frequency measurement
Power Factor PWR FACTOR TOTAL–00% Total power factor
