GEH-702 Users Manual
29
Table 25. Discrete Input, Function Code 2
Register Parameter Value
0 Long time pickup state 0 - Out 1 - In
1 Short time pickup state 0 - Out 1 - In
2 GF Sum Pickup state 0 - Out 1 - In
3 ZSI IN active 0 - On 1 - Off
4 ZSI-Out active (Output 3) 0 - On 1 - Off
5 Relay 1 Status (Output 1) 0 - On 1 - Off
6 Relay 2 Status (Output 2) 0 - On 1 - Off
8 GF Defeat 0 - On 1 - Off
9 Input 1 Status 0 - On 1 - Off
11 Relt Status 0 - Off 1 - On
21 Voltage Unbalance Status
0 - Normal
1 - Pickup
22 Under Voltage Status
0 - Normal
1 - Pickup
23 Over Voltage Status
0 - Normal
1 - Pickup
24 Current Unbalance Status
0 - Normal
1 - Pickup
25 Power Reversal Status
0 - Normal
1 - Pickup
27 Breaker position
0 - Open
1 - Closed
51 MET Tripped
0 - No
1 - Yes
54 WFC Data Available
0 - No
1 - Yes
56 Voltage Unbalance Alarm Status
0 - Normal
1 - Alarm
57 Under Voltage Alarm Status
0 - Normal
1 - Alarm
58 Over Voltage Alarm Status
0 - Normal
1 - Alarm
59 Current Unbalance Alarm Status
0 - Normal
1 - Alarm
60 Power Reversal Alarm Status
0 - Normal
1 - Alarm
61 GF Sum Alarm Status
0 - Normal
1 - Alarm
63 Load Shedding Status
0 - Normal
1 - Alarm
65 Diagnostic Mode status 0 - Off 1 - On
66 Defeatable GF 0 - Off 1 - On
