GE Industrial Solutions Spectra RMS Molded Case User Manual
Page 35

34
GEH-702 Users Manual
Register Address
Variable
Value
Factory Default
Read/Write
234
GF Trip Delay
0 - Off
1 - Band1
2 - Band2
3 - Band3
4 - Band4
5 - Band5
6 - Band6
7 - Band7
8 - Band8
9 - Band9
10 - Band10
11 - Band11
12 - Band12
13 - Band13
14 - Band14
15 - Band 15
5
Read/Write
235
GF K Value
0 -
1 -
2 -
3 -
0
Read/Write
236
GF Alarm Pickup
1 - 0.40
2 - 0.41
3 - 0.42
------
59 - 0.98
60 - 0.99
61 - 1.00
1
Read/Write
237
GF Alarm Delay
0 - Off
1 - Band1
2 - B and2
3 - Band3
4 - Band4
5 - Band5
6 - Band6
7 - Band7
8 - Band8
9 - Band9
10 - Band10
11 - Band11
12 - Band12
13 - Band13
14 - Band14
15 - Band 15
5
Read/Write
238
GF Alarm K Value
0 -
1 -
2 -
3 -
0
Read/Write
243
Current Unbalance Action
0 - Alarm
1 - Trip
2 - Both
0
Read/Write
244
Voltage Unbalance Action
0 - Alarm
1 - Trip
2 - Both
0
Read/Write
