GEH-702 Users Manual
25
Appendix A. Display Screen Flow
Table 20. Setup Mode Programming
Function Title (as implemented) Min. Value Max. Value Default Setting Setting Choices
Language LANGUAGE ENGLISH FRANÇAIS ENGLISH English, Français, Español,Deutsch, Chinese
Long Time
LONG TIME PICKUP 0.5 1.0 1.0 0.50X to 1.00X steps of 0.05X
LONG TIME DELAY BAND MVT1 F7 CB 6
MVT1-4, C1-C10, F1-F7
(Max. values vary by frame)
Short Time
SHORT TIME PICKUP 1.5 9.0 1.5 1.5C to 9.0C steps of 0.5C
SHORT TIME DELAY BAND 1 12 5 1 to 12 time bands
SHORT TIME SLOPE 0 3 0 0 to 3
Instantaneous INSTANTANEOUS PICKUP 2.0 25.5 2.0 2.0X to 14.0X steps of 0.5X
15.0X to 19.0X steps of 1.0X
20.5X to 25.0 steps of 1.5X
25.5X (Max. values vary by frame)
Reduced Energy
Let Through
RELT INST PICKUP 1.5 10 1.5 1.5X to 10.0X steps of 0.5X
Ground Fault
GF TRIP PICKUP 0.4 1.0 1.0 0.4S to 1.0S steps of 0.05S
GF TRIP DELAY BAND OFF 15 5 OFF or 2 to 15 time bands
GF TRIP SLOPE 0 3 0 0 to 3
GF ALARM PICKUP 0.4 1.0 1.0 0.4S to 1.0S steps of 0.05S
GF ALARM DELAY BAND OFF 15 5 OFF or 2 to 15 time bands
GF ALARM SLOPE 0 3 0 0 to 3
Zone Selective
Interlock
ZONE SEL INTLK OFF GF/ST/INST OFF GF, GF/ST, ST, ST/INST, GF/ST/INST
ZSI ST PICKUP 1.5 9.0 1.0 1.5C to 9.0C steps of 0.5C
ZSI ST DELAY BAND 1 12 6 1 to 12 time bands
ZSI ST SLOPE 0 3 0 0 to 3
ZSI GF PICKUP 0.4 1.0 1.0 0.4S to 1.0S steps of 0.05S
ZSI GF DELAY BAND OFF 15 5 OFF or 1 to 15 time bands
ZSI GF SLOPE 0 3 O 0 to 3
Neutral Protection NEUTRAL PROT OFF 150% OFF OFF, 50%, 100%, 150%
Protective Relays
PROT RLY ENABLE ON OFF OFF ON, OFF
VOLTAGE UNBAL PICKUP 10% 50% 10% 10% to 50% steps of 1%
VOLTAGE UNBAL DELAY OFF 15 1 OFF or 1 to 15 Seconds steps of 1 Second
TRIP ON ZERO V ON OFF OFF ON, OFF
CURRENT UNBAL PICKUP 10% 50% 10% 10% to 50% steps of 1%
CURRENT UNBAL DELAY OFF 15 1 OFF or 1 to 15 Seconds steps of 1 Second
UNDER VOLTAGE PICKUP 50% 90% 50% 50% to 90% steps of 1%
UNDER VOLTAGE DELAY OFF 15 1 OFF or 1 to 15 Seconds steps of 1 Second
OVER VOLTAGE PICKUP 110% 150% 110% 110% to 150% steps of 1%
OVER VOLTAGE DELAY OFF 15 1 OFF or 1 to 15 Seconds steps of 1 Second
POWER REVERSAL PICKUP 10 990 10 10KW to 990KW steps of 10KW
POWER REVERSAL DELAY 1 15 1 1 to 15 Seconds steps of 1 Second
LOAD ALARM ON 0.55 1.0 .55 0.55 to 1.00 xLT steps of 0.05
LOAD ALARM OFF 0.5 0.95 .5
0.50 to 0.95 xLT steps of 0.05
Note: OFF must be less than ON value
