26
GEH-702 Users Manual
Function Title (as implemented) Min. Value Max. Value Default Setting Setting Choices
Inputs and Outputs
INPUT 1 (if not RELT optioned) TRIP OFF OFF
RELAY 1 OFF GROUP 6
OFF [GROUP 6 if
RELT Enabled]
Fixed to GROUP 6 if RELT is optioned, else
available options are GROUP 1 to 5.
GROUP 1: GF Alarm
GROUP 2: Over Current Trip
GROUP 3: Protective Relay Trip
GROUP 4: Load Alarm
GROUP 5: Health Status
GROUP 6: RELT
RELAY 2 OFF GROUP 6
OFF [GROUP 6 if
RELT Enabled]
Available options are GROUP 1 to 6 if RELT
is optioned, else GROUP 1 to 5
Waveform
Capture
WAVEFORM CAPTURE DISABLE ALL ALL
Available options are:
Disable, Manual, OverCurrent, Protective
Relays, Manual/OverCurrent, Manual/
ProtectiveRelays, OverC urrent/
ProtectiveRelays, All
Frequency FREQUENCY 50Hz 60Hz 60 50Hz, 60Hz
Operating Voltage
PT VOLTAGE 100 690 480
100 to 690 Volts
steps of 1 Volt
PT CONNECTION PH-PH PH-N PH-PH PH-PH, PH-N
Power Direction POWER DIRECTION UP DOWN DOWN UP, DOWN
Phase Rotation
Setup
PHASE ROTATION ABC CBA ABC Available Options: ABC, CBA
Thermal Memory THERMAL MEMORY YES NO NO YES, NO
Auxiliary Switch AUX SWITCH INST YES NO NO YES, NO
Communications
MODBUS BAUDRATE 4800 19200 19200 4800 to 19200 standard baud increments
MODBUS ADDRESS 0 254 1 0 to 254 steps of 1
Date and Time
SET DATE Y/M/D
SET TIME H:M:S
