GEH-702 Users Manual
31
Table 27. Communication Parameters: Modbus Function 3 (Read/Write Parameters)
Register Address Variable Value Factory Default Read/Write
206 Neutral Pole Derating
0 - OFF
1 - 50%
2 - 100%
3 - 150%
0 Read/Write
207 ZSI Combination
0
1 - GF
2 - GF&ST
3 - ST
4 - ST & Inst
5 - GF & ST & Inst
0 Read/Write
208 PT Primary Voltage 100 - 690 120 Read/Write
209 PT Connection
0 - Ph-N
1 - Ph-Ph
1 Read/Write
211 Modbus Slave Address 1 - 247 1 Read/Write
213 Communication Setting
0 - 300-8N2
1 - 600-8N2
2 - 1200-8N2
3 - 2400-8N2
4 - 4800-8N2
5 - 9600-8N2
6 - 19200-8N2
7 - 300-8O1
8 - 600-8O1
9 - 1200-8O1
10 - 2400-8O1
11 - 4800-8O1
12 - 9600-8O1
13 - 19200-8O1
14 - 300-8E1
15 - 600-8E1
16 - 1200-8E1
17 - 2400-8E1
18 - 4800-8E1
19 - 9600-8E1
20 - 19200-8E1
21 - 300-8N1
22 - 600-8N1
23 - 1200-8N1
24 - 2400-8N1
25 - 4800-8N1
26 - 9600-8N1
27 - 19200-8N1
27 Read/Write
215 Long Time Trip Pickup
1 - 0.5
2 - 0.55
3 - 0.6
4 - 0.65
5 - 0.7
6 - 0.75
7 - 0.8
8 - 0.85
9 - 0.9
10 - 0.95
11 - 1.0
11 Read/Write
