GEH-702 Users Manual
Appendix B. Modbus Register Map.
Table 23. Status Screen Definitions
Function Title (as implemented) Data Presented Notes
Setting status SETTING STATUS
PU DLY
LT 1.0 4
ST 1.5 2
I 2.0 --
GF 0.4 4
Shows pickup and delay settings for
current protections
Pickup status PICKUP STATUS PICKUP Blank if not in pickup
Error status ERROR STATUS E08
E08 – Rating plug error
E03 – Internal Error
E04 – Internal Error
Breaker status BREAKER STATUS CLOSED/OPEN Only available if Aux switch is configured
Software version VERSION
SOFTWARE
VERSION
BUILD DATE
Communication settings COMM SETTING BAUD RATE PARITY
Table 24. Event Mode Screen Definitions
Function Title (as implemented) Data Presented Notes
Event Record Display EVENT 0
ST
Phase A
3
350
1/3/10 12:05
Event type
Phase
Number of occurrences
Magnitude of event
Date and time
EVENT 1 Same as event 0 Same as event 0
EVENT 2 Same as event 0 Same as event 0
EVENT 3 Same as event 0 Same as event 0
EVENT 4 Same as event 0 Same as event 0
EVENT 5 Same as event 0 Same as event 0
EVENT 6 Same as event 0 Same as event 0
EVENT 7 Same as event 0 Same as event 0
EVENT 8 Same as event 0 Same as event 0
EVENT 9 Same as event 0 Same as event 0
