GEH-702 Users Manual
33
Register Address Variable Value Factory Default Read/Write
225 Instantaneous Trip Pickup
0 - Off (For switchable Inst only)
1 - Invalid 19 - 10.5
2 - 2.0 20 - 11.0
3 - 2.5 21 - 11.5
4 - 3.0 22 - 12.0
5 - 3.5 23 - 12.5
6 - 4.0 24 - 13.0
7 - 4.5 25 - 13.5
8 - 5.0 26 - 14.0
9 - 5.5 27 - 15.0
10 - 6.0 28 - 16.0
11 - 6.5 29 - 17.0
12 - 7.0 30 - 18.0
13 - 7.5 31 - 19.0
14 - 8.0 32 - 20.5
15 - 8.5 33 - 22.0
16 - 9.0 34 - 23.5
17 - 9.5 35 - 25.0
18 - 10.0 36 - 25.5
2 Read/Write
226
Reduced Instantaneous Trip
Pickup
1 - 1.5
2 - 2
3 - 2.5
4 - 3
5 - 3.5
6 - 4
7 - 4.5
8 - 5
9 - 5.5
10 - 6
11 - 6.5
12 - 7
13 - 7.5
14 - 8
15 - 8.5
16 - 9
17 - 9.5
18 - 10
1 Read/Write
227 Aux Switch Installed
0 - No
1 - Yes
0 Read/Write
228 Phase Direction
0 - ABC
1 - CBA
0 Read/Write
233 GF Trip Pickup
1 - 0.40
2 - 0.41
3 - 0.42
------
59 - 0.98
60 - 0.99
61 - 1.00
61 Read/Write
