GE Industrial Solutions Spectra RMS Molded Case - Manual (Page 33)

32
GEH-702 Users Manual
Register Address Variable Value Factory Default Read/Write
216 Long Time Trip Delay
0 - Off
1 - MVT1
2 - MVT2
3 - MVT3
4 - MVT4
5 - C- Min
6~14 - C2..C10
15 - C-Max
16 - F-Min
17~22 - F2..F7
23 - F-Max
10 Read/Write
217 Thermal Memory Available
0 - OFF
1 - 12 min. cooling
0 Read/Write
219 Protective Relay Enable
0 - OFF
1 - ON
0 Read/Write
220 Frequency
0 - 50Hz
1 - 60Hz
1 Read/Write
222 Short Time Trip Pickup
1 - 1.5
2 - 2.0
3 - 2.5
4 - 3.0
5 - 3.5
6 - 4.0
7 - 4.5
8 - 5.0
9 - 5.5
10 - 6.0
11 - 6. 5
12 - 7.0
13 - 7.5
14 - 8.0
15 - 8.5
16 - 9.0
1 Read/Write
223 Short Time Trip Delay
0 - Off
1 - Band1
2 - Band2
3 - Band3
4 - Band4
5 - Band5
6 - Band6
7 - Band7
8 - Band8
9 - Band9
10 - Band10
11 - Band11
12 - Band12
5 Read/Write
224 Short Time Kst
0 - 0
1 - 2
2 - 8
3 - 18
0 Read/Write
