B&B Electronics, Inc. AirborneM2M™ User Manual
46 1/9/2014
Step Description
Optional
Press Restart [Button]
Restarts the device. After the device has
rebooted it will attempt to authenticate to the
configured network. As long as the network is
in range the wireless interface will connect.
Once authenticated to the network it is possible
for a TCP/IP connection to be made on the
Telnet port.
To establish a data tunnel and gain access to the serial data from the WLAN or
Ethernet interface follow the steps in Table 22.
Table 22 - Data Tunnel using Telnet Port
Step Description
Open TCP socket to device Using the WLAN IP Address and configured
telnet port number.
Authenticate with device authdpacdpac
Any user level above L5 can authenticate with
the unit.
Device responds OK
Open data tunnel to serial port pass-x
Where x can be p1, p2 or any.
p1orp2 binds to the indicated serial port, as
long as the serial port is in listen mode and
does not already have a data tunnel open.
Any binds to the first serial port which is in
listen mode and does not already have a data
tunnel open.
15.2 Configuring Serial Port 1 for Access on Tunnel Port
A data tunnel can be made using the device ’s tunnel port as the network
connection port. This does not require authenticating with the device and
automatically initiates the tunnel connection. Configuring the device to support
this approach is covered in the following table.
Table 23 – Configure Data Tunnel on Serial Port 1 Tunnel Port (TCP)
Step Description
Navigation Bar
Select Configuration
You will see a group of fields under the banner
of WLAN Parameters.
Feature Link
Select Connection Settings
The wireless interface and security must be
configured before configuring the Ethernet
settings.
A page appears showing the configuration
options for TCP/IP and UDP connections to the
device. Configuration of Telnet, HTTP and SSH
ports can be done on this page.
Select Tunnel Enabled Select Enabled.
