B&B Electronics, Inc. AirborneM2M™ User Manual
16 1/9/2014
6.0
Electrical& RF Specification
Table 7- Absolute Maximum Values 1
Parameter Min Max Unit
Maximum Supply Voltage 5.0 36 VDC
PoE 802.3af Class1 – Q5xx8 models 37 57 VDC
Power Dissipation 3.00 W
Operating Temperature Range -40 85 o C
Storage Temperature -40 85 o C
Note: 1. Values are absolute ratings, exceeding these values may cause permanent damage to the device.
Table 8 - RF Characteristics – 802.11a/b/g/n
Symbol Parameter Rate (Mb/s) Min
Average
dBm / mW
Peak
dBm / mW
Units
P
OUTB
Transmit Power
Output 802.11b
11, 5.5, 2, 1 15.0 31.6 dBm
P
OUTG
Transmit Power
Output 802.11g 6, 9, 12, 18, 24,
36, 48, 54
12.6 18.2 dBm
P
OUTA
Transmit Power
Output 802.11a
6, 9, 12, 18, 24,
36, 48, 54
17.0 50.1 dBm
P
RSENB
Receive
Sensitivity
802.11b
11 -86
dBm
1 -92
P
RSENG
Receive
Sensitivity
802.11g
54 -72
dBm
36 -78
18 -84
6 -89
P
RSENA
Receive
Sensitivity
802.11a
54 -74
dBm
36 -80
18 -86
6 -90
F
RANGEBG
Frequency
Range
2412 2484 MHz
F
RANGEA
Frequency
Range
802.11a
4910
5150
5470
4990
5350
5825
MHz

The transmit power is automatically controlled by the device for minimum power
consumption.
The transmit power at the antenna connector is listed in Table 8 above (±2dBm).
