B&B Electronics, Inc. AirborneM2M™ User Manual
14 1/9/2014
5.3 Connector Definition
The AirborneM2M ™ device has five connectors. Table 4 provides definitions for
the connectors.
Table 4 - Connector Description
Type Description
Serial DE-9 Connector Male
Ethernet RJ45 Socket
Antenna RP-SMA
Power 2.1mm Barrel Jack
Power 2 Position Terminal Block
5.4 Default Switch (Factory Reset)
The AirborneM2M ™ device will let you reset the configuration back to OEM
defaults and start over again. This is useful when a device has been incorrectly
configured. An incorrect configuration can make it impossible to communicate on
any of the available ports. That would prevent access to the configuration
interfaces and block your ability to correct the configuration.
Performing a Factory RESET will return the device to the original OEM defaults.
If no OEM configuration is installed the device will return to the B&B factory
defaults. That will restore your ability to communicate with the device.
The following Table 5 describes the sequence for resetting the AirborneM2M ™
device to the OEM defaults
Table 5 - Reset Procedure
1 Disconnect or turn off the power supply.
2
Press and hold in the Default (factory reset) button.
This may require the use of a small, narrow object. Do not use anything sharp, as
that may damage the unit.
3 While the Default button is pressed and held in, re-apply power to the unit.
4
Continue to hold in the Default button for 5-6 seconds after power has been
applied.
5 Release the Default button.
