B&B Electronics, Inc. AirborneM2M™ User Manual
38 1/9/2014
Step Description
Select Discovery OEM Device Name This parameter allows you to name the device uniquely or
group it into a functional set. When device discovery is used this
name identifies the found device.
If you wanted to uniquely identify the device you could mark it
with a label like Dev1, for example, and then enter Dev1 in this
field. When the device is found it will identify itself as Dev1.
Alternately you could indicate the type of equipment the device
is attached to, like a Haas TL-2 (CNC Turning Center), by giving
the unit a name like Haas_TL_2. When discovered you can then
identify the device you are accessing.
Enter the text string if you wish to change the default value.
This field is optional.
Select Radio Startup Mode Select On from the drop down menu for the radio to operate.
Select WLAN Connection Type Default mode is Access Point. To use the device as a wireless
router (default mode) or as an Infrastructure Access Point
(member of an existing wireless network) the connection type
should be Access Point.
Select SSID Enter the name of the wireless network you wish to setup. This
field is case sensitive and may include spaces.
Select Wireless LAN Security Type Select the security type you wish to use with your wireless
network.
Depending upon the option you choose you may have to enter
additional information. Once you have selected the security type
the required inputs will be displayed. All displayed fields must
be completed.
If an option is displayed, but grayed out, that option is
unavailable in Access Point mode.
Select Ethernet Role The default setting is Wireless Router. In this mode devices on
the wired port are assigned static IP addresses or there must be
a DHCP server on the network. A firewall and port forwarding
are available to allow/restrict access between the WLAN and
Ethernet networks.
Change this to Bridge if your application has Ethernet devices
on the wired port. All devices can be on the same subnet and
wireless clients will have access to resources on the wired port.
Select WLAN Channel This is the channel the Access Point will use to communicate
with clients. It is recommended that you use only one Access
Point per channel.
The default is 1.
Select Wireless DHCP Server Enabled When Enabled this will provide IP addresses to clients that are
using a DHCP client for IP address assignment. (Router mode)
When the Ethernet port is in Bridge mode, the DHCP server will
provide IP addresses for Ethernet clients also.
Select WLAN DHCP This parameter is ignored in AP mode.
Select Ethernet DHCP The function of this field depends upon the Ethernet mode
setting.
If Ethernet mode is Client; enabling this will cause the Ethernet
interface to obtain an IP address from a DHCP on the network
attached to the Ethernet port.
If Ethernet Mode or Bridge is Router; This parameter is
ignored.
