AirborneM2M™ Users Guide B&B Electronics, Inc.
1/9/2014 39
Step Description
Select WLAN Static IP The function of this field depends upon whether or not the
DHCP Server is enabled on the WLAN interface.
If the DHCP Server is disabled, this field defines the static IP
address for the wireless interface.
If the DHCP Server is enabled, this field defines the first IP
address leased by the DHCP server. Addresses are incremented
as new clients are leased addresses.
Default: 192.168.10.100
Select WLAN Subnet Mask The function of this field depends upon whether or not the
DHCP Server is enabled on the WLAN interface.
If the DHCP Server is disabled, this field defines the subnet
mask used by the wireless interface.
If the DHCP Server is enabled, this field defines the subnet
mask provided by the DHCP server.
Default: 255.255.255.0
Select WLAN Gateway Address The function of this field depends upon whether or not the
DHCP Server is enabled on the WLAN interface.
If the DHCP Server is disabled, this field defines the gateway
IP address used by the wireless interface.
If the DHCP Server is enabled, this field defines the gateway IP
address provided by the DHCP server.
If the DHCP Server is enabled, this field defines the IP address
of the WLAN interface of the APXx.
Default: 192.168.10.1
Select Ethernet Static IP The function of this field depends upon whether or not the
Ethernet Mode setting.
If Ethernet Mode is Client, this field defines the IP address to
be used if DHCP is not being used or if DHCP fails.
If Ethernet Mode is Bridge or Router, this field defines the
static IP address to be used by the Ethernet interface.
When the Ethernet Mode is Bridge it is recommended that this
field be set to an IP address within the same subnet as the
WLAN Static IP address.
Default: 192.168.2.100
Select Ethernet Subnet Mask This field defines the subnet to be used with the Ethernet Static
IP address.
Default: 255.255.255.0
Select Ethernet Gateway Address This field defines the Gateway IP address to be used by the
Ethernet port.
Default: 0.0.0.0
(Optional) Select Web Server Port Only displayed when Ethernet Mode is set to Bridge.
Defines the port number used by the device for HTTP access
(web interface).
It is recommended that this be changed from the default 80.
(Optional) Select Telnet Port Only displayed when Ethernet Mode is set to Bridge.
Defines the port number used by the device for Telnet & TCP/IP
access (CLI interface).
(Optional) Select Internal FTP Server
Listen Port Only displayed when Ethernet Mode is set to Bridge.
Defines the port number used by the device to listen for FTP
access.
(Optional) Select Secure Shell Server
(SSH) Port
Only displayed when Ethernet Mode is set to Bridge.
Defines the port number used by the device to listen for SSH
access.
Press Commit [Button] Saves changes to the device.
