Section 1 - Introduction Vlinx VESR4x4 Serial Server
Page 9 of 70
www.bb-elec.com/
www.bb-europe.com/
VESR4x4 Features
 VESR424x-xx series models – two Ethernet connectors
 Ethernet Fiber port models available
 Ethernet pass through ports (on two Ethernet port models)
 Multi-interface serial ports (RS-232, RS-422, RS-485)
 DB-9M and pluggable terminal block serial port connector options
 All serial ports are software selectable for RS-232, RS-422 or RS-485 2-
and 4-wire communication
 Configuration can be done via network or direct serial connection
 Rugged metal case, DIN rail or panel mountable
 Accepts DC power over a wide voltage range
 Two power connections (pluggable terminal strip and locking barrel
connector) can be used for redundant power supply
NOTE: the terminal block must be used for Class 1 Division 2
applications; the barrel jack cannot be used for these applications. See
the specification tables for further information.
 10/100 Mbps Ethernet with Auto Selection
 TCP Client or Server, or UDP operation - configurable
 Virtual COM port and Paired Mode capabilities
 Firmware Upload over the Ethernet port for future revisions/upgrades
 Software Support - Windows 2000, XP (32/64 bit), 2003 Server (32/64
bit), Vista (32/64 bit), 2008 Server (32/64 bit), Windows 7 (32/64 bit)
 Configuration of Ethernet and serial port settings using Vlinx Manager
software or built-in web server
Vlinx Manager Configuration Software
Vlinx Manager configuration software enables you to find connected serial
servers, configure them, upgrade serial server firmware, and save/load
configuration files. It features a graphical user interface (GUI) that is
convenient and easy to use. The software also makes it easy to add and
remove virtual COM ports on your computer.
