Section 8 - Appendix Vlinx VESR4x4 Serial Server
Page 64 of 70
www.bb-elec.com/
www.bb-europe.com/
Appendix B: Product Specifications
General Specifications
Hardware and
included accessories
Device Serial Server
CD
CD with Vlinx Manager Software for
Windows 2000, XP (32/64 bit), 2003 Server (32/64 bit), Vista (32/64 bit), 2008
Server (32/64 bit), Windows 7 (32/64 bit)
Optional Accessories
Cable 232NM9 Null Modem Crossover Cable for DTE to DTE connection
Rail ERS35 one-meter length of steel 35mm DIN Rail
Mounting Bracket Kit
#9030
Configuration Options
Via serial port
Using Vlinx Manager via a serial connection, (press Reset button to enter Console
Mode)
Via network
Using Vlinx Manager via a Ethernet connection
Using a standard web browser such as Internet Explorer 7, 8 or 9 or Firefox 3 or 4
Software
Vlinx Manager for
serial server
configuration
Windows 2000, XP (32/64 bit), 2003 Server (32/64 bit), Vista (32/64 bit), 2008
Server (32/64 bit), Windows 7 (32/64 bit)
Environment
Operating
Temperature
-40 to 80 °C (-40 to 176 °F)
Storage Temperature -40 to 85 °C (-40 to 185 °F)
Operating Humidity 10 to 95% non-condensing
Maximum Ambient
Surrounding Air Temp
80 °C
Certifications
FCC Part 15 Class A
UL Class 1, Div. 2, Groups A, B, C, D
CE
NEMA TS2
Enclosure
Rating IP30
Mounting DIN rail mount (35 mm)
Dimensions
(VESR4x4)
1.8 x 4.4 x 6.75 in (4.57 x 12.2 x 17.1 cm)
Power Supply
Voltage Requirements 10 to 48 VDC (58 VDC Max)
Power Consumption 6.0 watts maximum
Locking barrel
connector input:
Voltage requirements:
10 to 30 VDC maximum
Class 2 grounded type supply only
NOTE: Coaxial power cable must be in accordance with Class 2 requirements in Article 725 of the NEC.
The locking barrel connector must NOT be used in a hazardous environment.
Terminal Blocks
Wire Size 28 to 16 AWG
Wire Type Copper Wire Only
Tightening Torque 5 KG-CM
Wire Temp Rating
105 °C Minimum
Sized for 60 °C Ampacity
Note: One Conductor Per Terminal
