DS26502 T1/E1/J1/64KCC BITS Element
84 of 125
Register Name: LIC2
Register Description: Line Interface Control 2
Register Address: 31h
Bit
# 7 6 5 4 3 2 1 0
Name — LIRST IBPV TAIS JACKS RCCFE SCLD CLDS
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0
TAIS
PIN 10
JACKS
PIN 46
0 0 0
Bit 0/Custom Line Driver Select (CLDS). Setting this bit to a one will redefine the operation of the transmit line driver.
When this bit is set to a one and LIC1.5 = LIC1.6 = LIC1.7 = 0, then the device will generate a square wave at the TTIP and
TRING outputs instead of a normal waveform. When this bit is set to a one and LIC1.5 = LIC1.6 = LIC1.7
¹ 0, then the device
will force TTIP and TRING outputs to become open-drain drivers instead of their normal push-pull operation. This bit should
be set to zero for normal operation of the device. Note: This bit should be set = 0 in 64KCC and 6312kHz transmit modes.
Bit 1/Short Circuit Limit Disable (in E1 mode) (SCLD). Controls the 50mA (rms) current limiter. Note: Not applicable in
6312kHz mode.
0 = enable 50mA current limiter
1 = disable 50mA current limiter
Bit 2/ Receive Composite Clock Filter Enable (RCCFE).
(64KCC mode only) Setting this bit will enable the PLL filter on
the received 64kHz composite clock. Note: the 8kHz and 400Hz output are not filtered.
0 = Receive Composite Clock Filter Disabled
1 = Receive Composite Clock Filter Enabled
Bit 3/Jitter Attenuator Mux (JACKS). Controls the source for JA CLOCK. This bit is only used in T1 mode.
0 = JA CLOCK sourced from the pre-scaled MCLK
1 = JA CLOCK sourced from internal PLL
Bit 4/Transmit Alarm Indication Signal (TAIS).
0 = transmit an unframed all-ones code
1 = transmit data normally
Bit 5/Insert BPV (IBPV). A zero-to-one transition on this bit will cause a single BPV to be inserted into the transmit data
stream. Once this bit has been toggled from a zero to a one, the device waits for the next occurrence of three consecutive ones
to insert the BPV. This bit must be cleared and set again for a subsequent error to be inserted. Note: This function not
supported in 64KCC and 6312kHz modes.
Bit 6/Line Interface Reset (LIRST). Setting this bit from a zero to a one will initiate an internal reset that resets the clock
recovery state machine and recenters the jitter attenuator. Normally this bit is only toggled on power-up. Must be cleared and
set again for a subsequent reset.
Bit 7/Unused, must be set = 0 for proper operation.
