DS26502 T1/E1/J1/64KCC BITS Element
111 of 125
19. OPERATING PARAMETERS
ABSOLUTE MAXIMUM RATINGS
Voltage Range on Any Pin Relative to Ground………………………………………………………-1.0V to +6.0V
Operating Temperature Range for DS26502L…………………………………………………………0°C to +70°C
Operating Temperature Range for DS26502LN……………………………………………………..-40°C to +85°C
Storage Temperature Range………………………………………………………………………...-55°C to +125°C
Soldering Temperature…………………………………………………...See IPC/JEDEC J-STD-20A Specification
This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operation
sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods of time can affect reliability.
Table 19-1. Thermal Characteristics
PARAMETER MIN TYP MAX NOTES
Ambient Temperature -40°C +85 °C 1
Junction Temperature 125 °C
Theta-JA ( q
JA
) in Still Air 46.3 °C/W 2
Table 19-2. Theta-JA ( q
JA
) vs. Airflow
FORCED AIR
(meters per second)
THETA-JA ( q
JA
)
0 (Note 3)
1 (Note 3)
2.5 (Note 3)
Note 1: The package is mounted on a four-layer JEDEC standard test board.
Note 2:
Theta-JA ( q
JA
) is the junction-to-ambient thermal resistance, when the package is mounted on a
four-layer JEDEC standard test board.
Note 3: At the time of release of this data sheet, these values were not available. Please consult the factory.
Table 19-3. Recommended DC Operating Conditions
(T
A
= 0°C to +70°C for DS26502L; T
A
= -40°C to +85°C for DS26502LN.)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 V
IH
2.0 5.5 V
Logic 0 V
IL
-0.3 +0.8 V
Supply V
DD
3.135 3.3 3.465 V 4
Note 4: Applies to RVDD, TVDD, and DVDD.
Table 19-4. Capacitance
(T
A
= +25°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF
Output Capacitance C
OUT
7 pF
