DS26502 T1/E1/J1/64KCC BITS Element
54 of 125
Register Name:
IOCR2
Register Description: I/O Configuration Register 2
Register Address: 02h
Bit
# 7 6 5 4 3 2 1 0
Name
RCLKINV TCLKINV RS_8KINV TS_8K_4INV — — — —
Default 0 0 0 0 0 0 0 0
HW
Mode
0 0 0 0 0 0 0 0
Bit 0/Unused, must be set = 0 for proper operation.
Bit 1/Unused, must be set = 0 for proper operation.
Bit 2/Unused, must be set = 0 for proper operation.
Bit 3/Unused, must be set = 0 for proper operation.
Bit 4/TS_8K_4 Invert (TS_8K_4INV).
0 = no inversion
1 = invert
Bit 5/RS_8K Invert (RS_8KINV).
0 = no inversion
1 = invert
Bit 6/TCLK Invert (TCLKINV).
0 = no inversion
1 = invert
Bit 7/RCLK Invert (RCLKINV).
0 = no inversion
1 = invert
