MAX5965A/MAX5965B
High-Power, Quad, Monolithic, PSE Controllers
for Power over Ethernet
40 ______________________________________________________________________________________
Table 29. High-Power Mode Register
ADDRESS = 24h
SYMBOL BIT R/W
DESCRIPTION
Reserved 7 — Reserved
6 R/W HP[2]
5 R/W HP[1] HP
4 R/W HP[0]
3 — Reserved
2 — Reserved
1 — Reserved
Reserved
0 — Reserved
Table 30. Reserved Register (25h)
ADDRESS = 25h
SYMBOL BIT R/W
DESCRIPTION
7 — Reserved
6 — Reserved
5 — Reserved
4 — Reserved
3 — Reserved
2 — Reserved
1 — Reserved
Reserved
0 — Reserved
Table 31. Reserved Register (26h)
ADDRESS = 26h
SYMBOL BIT R/W
DESCRIPTION
7 — Reserved
6 — Reserved
5 — Reserved
4 — Reserved
3 — Reserved
2 — Reserved
1 — Reserved
Reserved
0 — Reserved
HP[2:0] programs the default power setting that is writ-
ten upon the discovery of a class 4, 5, or 6 PD. A reset
or power-up sets R24h = 00h.
