The ID register (Table 24) keeps track of the device ID
number and revision. The MAX5965A/MAX5965B’s ID_CODE[4:0] = 11000b. Contact the factory for
REV[2:0] value.
Table 23. Global Pushbuttons Register
ADDRESS = 1Ah
SYMBOL BIT R/W
DESCRIPTION
CLR_INT 7 W A logic-high clears all interrupts
Reserved 6 — Reserved
Reserved 5 — Reserved
RESET_IC 4 W A logic-high resets the MAX5965A/MAX5965B
RESET_P4 3 W A logic-high resets port 4
RESET_P3 2 W A logic-high resets port 3
RESET_P2 1 W A logic-high resets port 2
RESET_P1 0 W A logic-high resets port 1
Table 24. ID Register
ADDRESS = 1Bh
SYMBOL BIT R/W
DESCRIPTION
7 R ID_CODE[4]
6 R ID_CODE[3]
5 R ID_CODE[2]
4 R ID_CODE[1]
ID_CODE
3 R ID_CODE[0]
2 R REV[2]
1 R REV[1] REV
0 R REV[0]
Writing a 1 to CLR_INT (Table 23) clears all the event
registers and the corresponding interrupt bits in regis-
ter R00h. Writing a 1 to RESET_P_ turns off power to the
corresponding port and resets only the status and event registers of that port. After execution, the bits
reset to 0. Writing a 1 to RESET_IC causes a global
software reset, after which the register map is set back
to its reset state. A reset sets R1Ah = 00h.
