W25Q80, W25Q16, W25Q32
Publication Release Date: June 20, 2007
- 51 - Advanced - Revision A5
11.8 AC Electrical Characteristics ( cont’d)
SPEC
DESCRIPTION SYMBOL ALT
MIN TYP MAX
UNIT
/HOLD Active Hold Time relative to CLK t CHHH 5 ns
/HOLD Not Active Setup Time relative to CLK t HHCH 5 ns
/HOLD Not Active Hold Time relative to CLK t CHHL 5 ns
/HOLD to Output Low-Z t HHQX
(2) t LZ 7 ns
/HOLD to Output High-Z t HLQZ
(2) t HZ 12 ns
Write Protect Setup Time Before /CS Low t WHSL
(3) 20 ns
Write Protect Hold Time After /CS High t SHWL
(3) 100 ns
/CS High to Power-down Mode t DP
(2) 3 µs
/CS High to Standby Mode without Electronic
Signature Read t RES 1 (2) 3 µs
/CS High to Standby Mode with Electronic Signature
Read t RES 2 (2) 1.8 µs
/CS High to next Instruction after Suspend t SUS
(2) 20 µs
Write Status Register Time t W 10 15 ms
Byte Program Time (First Byte) (5) t
BP1
100 150 µs
Additional Byte Program Time (After First Byte) (5) t
BP2
6 12 µs
Page Program Time t PP 1.5 3 ms
Sector Erase Time (4KB) t SE 120 200 ms
Block Erase Time (32KB) t BE
1
0.5 1 s
Block Erase Time (64KB) t BE
2
0.75 1.5 s
Chip Erase Time W25Q80
Chip Erase Time W25Q16
Chip Erase Time W25Q32 t CE 12
25
50
25
40
80 s
s
s
Notes:
1. Clock high + Clock low must be less than or equal to 1/f C .
2. Value guaranteed by design and/or characterization, not 100% tested in production.
3. Only applicable as a constraint for a Write Status Register instruction when Sector Protect Bit is set to 1.
4. Commercial temperature only applies to Fast Read (F
R0
& F
R1
). Industrial temperature applies to all other parameters.
5. For multiple bytes after first byte within a page, t
BPN
= t
BP1 +
t
BP2 * N
(typical) and t
BPN
= t
BP1 +
t
BP2 * N
(max), where N =
number of bytes programmed.
