W25Q80, W25Q16, W25Q32
- 46 -
11. ELECTRICAL CHARACTERISTICS (P RELIMINARY ) (4)
11.1 Absolute Maximum Ratings (1)
PARAMETERS SYMBOL CONDITIONS RANGE UNIT
Supply Voltage VCC –0.6 to +4.0 V
Voltage Applied to Any Pin V IO Relative to Ground –0.6 to VCC +0.4 V
Transient Voltage on any Pin V IOT
<20nS Transient
Relative to Ground
–2.0V to VCC+2.0V V
Storage Temperature T STG –65 to +150 °C
Lead Temperature T LEAD See Note (2) °C
Electrostatic Discharge Voltage V ESD Human Body Model (3) –2000 to +2000 V
Notes:
1. This device has been designed and tested for the specified operation ranges. Proper operation
outside of these levels is not guaranteed. Exposure to absolute maximum ratings may affect device
reliability. Exposure beyond absolute maximum ratings may cause permanent damage.
2. Compliant with JEDEC Standard J-STD-20C for small body Sn-Pb or Pb-free (Green) assembly and
the European directive on restrictions on hazardous substances (RoHS) 2002/95/EU.
3. JEDEC Std JESD22-A114A (C1=100 pF, R1=1500 ohms, R2=500 ohms).
4. See preliminary designation at the end of this datasheet.
11.2 Operating Ranges
SPEC
PARAMETER SYMBOL CONDITIONS
MIN MAX
UNIT
Supply Voltage (1) VCC
F
R
= 80MHz, F
R1
& f R = 50MHz,
F
R1
= 70MHz
2.7
3.0
3.6
3.6
V
Ambient Temperature,
Operating
T A
Commercial
Industrial
0
–40
+70
+85
°C
Note:
1. VCC voltage during Read can operate across the min and max range but should not exceed ±10% of the programming
(erase/write) voltage.
