W25Q80, W25Q16, W25Q32
Publication Release Date: June 20, 2007
- 17 - Advanced - Revision A5
STATUS REGISTER
(1)
W25Q80 (8M-BIT) MEMORY PROTECTION
SEC TB BP2 BP1 BP0 BLOCK(S)
ADDRESSES
DENSITY
PORTION
X X 0 0 0 NONE
NONE
NONE
NONE
0
0
0
0
1
15
0F0000h - 0FFFFFh
64KB
Upper 1/16
0
0
0
1
0
14 and 15
0E0000h - 0FFFFFh
128KB
Upper 1/8
0
0
0
1
1
12 thru 15
0C0000h - 0FFFFFh
256KB
Upper 1/4
0
0
1
0
0
8 thru 15
080000h - 0FFFFFh
512KB
Upper 1/2
0
1
0
0
1
0
000000h - 00FFFFh
64KB
Lower 1/16
0
1
0
1
0
0 and 1
000000h - 01FFFFh
128KB
Lower 1/8
0
1
0
1
1
0 thru 3
000000h - 03FFFFh
256KB
Lower 1/4
0
1
1
0
0
0 thru 7
000000h - 07FFFFh
512KB
Lower 1/2
X
X
1
1
X
0 thru 15
000000h – 0FFFFFh
1MB
ALL
1
0
0
0
1
15
0FF000h – 0FFFFFh
4KB
Top Block
1
0
0
1
0
15
0FE000h – 0FFFFFh
8KB
Top Block
1
0
0
1
1
15
0FC000h – 0FFFFFh
16KB
Top Block
1
0
1
X
X
15
0F8000h – 0FFFFFh
32KB
Top Block
1
1
0
0
1
0
000000h – 000FFFh
4KB
Bottom Block
1
1
0
1
0
0
000000h – 001FFFh
8KB
Bottom Block
1
1
0
1
1
0
000000h – 003FFFh
16KB
Bottom Block
1
1
1
X
X
0
000000h – 007FFFh
32KB
Bottom Block
Note:
1. x = don’t care
