W29EE512
64K
×
8 CMOS FLASH MEMORY
Publication Release Date: April 2000
- 1 - Revision A6
GENERAL DESCRIPTION
The W29EE512 is a 512K bit, 5-volt only CMOS flash memory organized as 64K
×
8 bits. The device
can be programmed and erased in-system with a standard 5V power supply. A 12-volt V PP is not
required. The unique cell architecture of the W29EE512 results in fast program/erase operations with
extremely low current consumption (compared to other comparable 5-volt flash memory products).
The device can also be programmed and erased using standard EPROM programmers.
FEATURES
• Single 5-volt program and erase operations
• Fast page-write operations
−
128 bytes per page
−
Page program cycle: 10 mS (max.)
−
Effective byte-program cycle time: 39
µ
S
−
Optional software-protected data write
• Fast chip-erase operation: 50 mS
• Read access time: 70/90/120 nS
• Typical page program/erase cycles: 1K/10K
• Ten-year data retention
• Software and hardware data protection
• Low power consumption
−
Active current: 50 mA (max.)
−
Standby current: 100
µ
A (max.)
• Automatic program timing with internal V PP
generation
• End of program detection
−
Toggle bit
−
Data polling
• Latched address and data
• TTL compatible I/O
• JEDEC standard byte-wide pinouts
• Available packages: 32-pin PLCC, TSOP and
VSOP
