Preliminary W49L102
64K
×
16 CMOS 3.3V FLASH MEMORY
Publication Release Date: June 1999
- 1 -
Revision A1
GENERAL DESCRIPTION
The W49L102 is a 1-megabit, 3.3-volt only CMOS flash memory organized as 64K
×
16 bits. The
device can be programmed and erased in-system with a standard 3.3V power supply. A 12-volt V
PP
is
not required. The unique cell architecture of the W49L102 results in fast program/erase operations
with extremely low current consumption (compared to other comparable 3.3-volt flash memory
products). The device can also be programmed and erased using standard EPROM programmers.
FEATURES
•
Single 3.3-volt operations:
−
3.3-volt Read
−
3.3-volt Erase
−
3.3-volt Program
•
Fast Program operation:
−
Word-by-Word programming: 50
µ
S (max.)
•
Fast Erase operation: 100 mS (typ.)
•
Fast Read access time: 55/70/90 nS
•
Endurance: 1K/10K cycles (typ.)
•
Twenty-year data retention
•
Hardware data protection
•
8K word Boot Block with Lockout protection
•
Low power consumption
−
Active current: 15 mA (typ.)
−
Standby current: 10
µ
A (typ.)
•
Automatic program and erase timing with
internal V
PP
generation
•
End of program or erase detection
−
Toggle bit
−
Data polling
•
Latched address and data
•
TTL compatible I/O
•
JEDEC standard word-wide pinouts
•
Available packages: 40-pin TSOP and 44-pin
PLCC
