MAX9257/MAX9258
16 ______________________________________________________________________________________
Fully Programmable Serializer/Deserializer
with UART/I
2
C Control Channel
V OLMAX
t HIGH
t LOW
t
T
V OHMIN
PCLK_OUT
Figure 10. MAX9258 Clock Output High and Low Time
PCLK_OUT
t DVB t
DVA
V OHMIN
V OLMAX
V OHMIN
V OLMAX
NOTE: PCLK_OUT PROGRAMMED FOR RISING LATCHING EDGE.
DOUT, VSYNC_OUT,
HSYNC_OUT, LOCK
Figure 11. MAX9258 Output Data Valid Times
PD
POWERED DOWN
t PUD
POWERED UP
(OUTPUTS ACTIVE)
V IHMIN
Figure 12. MAX9258 Power-Up Delay
PD
HIGH IMPEDANCE
DOUT,
VSYNC,
HSYNC
POWERED DOWN POWERED UP
t PDD
V ILMAX
Figure 13. MAX9258 Power-Down Delay
