MAX9257/MAX9258
14 ______________________________________________________________________________________
Fully Programmable Serializer/Deserializer
with UART/I
2
C Control Channel
SDO-
C L C L
R L
SDO+
t
FALL
20% 20%
(SDO+) - (SDO-)
80% 80%
t RISE
Figure 4. MAX9257 LVDS Control Channel Output Load and Output Rise/Fall Times
V IHMIN
V IHMIN V IHMIN
V ILMAX
V ILMAX
V ILMAX
PCLK_IN
DIN, VSYNC_IN, HSYNC_IN
t HOLD t SET
NOTE: PCLK_IN PROGRAMMED FOR RISING LATCHING EDGE.
Figure 5. MAX9257 Input Setup and Hold Times
