MAX9257/MAX9258
______________________________________________________________________________________ 13
Fully Programmable Serializer/Deserializer
with UART/I 2 C Control Channel
SDO-
V OD
V
OS
GND
R L /2
R L /2
SDO+
SDO-
SDO+
(SDO+) - (SDO-)
V OS (-) V OS (+)
((SDO+) + (SDO-))/2
V OS (-)
V OD (-) V OD (-)
V OD = 0V
ΔV
OS = | V OS (+) - V OS (-) |
ΔV
OD = | V OD (+) - V OD (-) |
V OD (+)
Figure 1. MAX9257 LVDS DC Output Parameters
V ID = 0V
+V ID -V ID
V OUT
V HYST+ V HYST-
Figure 2. Input Hysteresis
PCLK_IN
NOTE: PCLK_IN PROGRAMMED FOR RISING LATCH EDGE.
DIN
Figure 3. MAX9257 Worst-Case Pattern Input
