6-2

••••

Specifications

9229-QS User Manual

••••

(V 1.2)

RM20-9229-C Specifications

Table 6.2 provides technical specifications when using the RM20-9229-C Rear Module.

Table 6.2 9229-QS Technical Specifications – RM20-9229-C

Category

Parameter

Specification

Number of Looping Inputs

4

SDI Data Rates and SMPTE Standards
Accommodated

SMPTE 259M (270Mbps) SMPTE
292M (1.485 Gbps)

Impedance

75 Ohms

Return Loss

Not applicable for looping input

Serial Digital Video

Inputs

Equalization

50m

Number of Outputs

4

Number of Looping Outputs

4

Impedance

75 Ohms

Return Loss

OUT 1-4: <15dB, 0 to 1.5GHz

Signal Level

800mV +/-10%

DC Offset

0+/-50mV

Rise and Fall Time

SD: 900ps typical

HD: 150ps typical

Serial Digital Video

Outputs

Overshoot

<10% typical

Other

Power Consumption

22W
