9229-QS User Manual

••••

(V 1.2)

Appendix A. DashBoard Menus

••••

5-3

Tab Title

Item

Parameters

Description

Red - No reference

No signal detected on selected reference input

Red - Reference Unlocked

Signal detected, but not locked (or lock lost)

Red - Invalid Reference

Signal detected, but incompatible with the
current video mode

Unknown

No signal present, or format is not recognized

480i 59.94

Composite NTSC reference detected

720p 59.94

1080i 59.94

Tri-level sync at 59.94Hz detected

576i 50

Composite PAL reference detected

720p 50

1080i 50

Tri-level sync at 50Hz detected

1080PsF 24

Progressive segmented frames at 24Hz

Reference Format

1080PsF 23.98

Progressive segmented frames at 23.98Hz

Green - OK

Normal operation

Green - Alarm Suppressed

An alarm condition exists but is silenced

Yellow - Incompatible format

Signal present but format does not match the
video output format configuration of the card

Bkgd A Status

Red - No signal

No signal present on the input

Bkgd B Status

Same parameters as above

Bkgd C Status

Same parameters as above

Bkgd D Status

Same parameters as above

Green - Normal (not in
bypass)

Video is being routed through the card; Quad
Split may be active

Bypass Relay

Red - Active (in bypass)

BKGD A bypasses the card and is looped
passively on Output 1 through the relay

Relative to Reference

The BKGD Timing fields display the timing
values relative to the selected analog reference

Timing Display

Input to Output

The BKGD Timing fields display the timing
values relative to the SDI output of the card

## clocks ## lines

Indicates the timing of the BKGD A input signal
relative to the reference signal or relative to the
output as specified in the Timing Display
feature where 1 clock is:

1 period of 27MHz (SD), or

1 period of 148.x MHz (HD)

Signal (Read-
only)

Bkgd A Timing

Green status

Indicates that the timing is within the specified
range for the card
