9229-QS User Manual

••••

(V 1.2)

Appendix A. DashBoard Menus

••••

5-11

Quad Split Menus

The following table summarizes the Quad Split tab options available in DashBoard.

Table 5.8 Quad Split Options

Menu

Item

Parameters

Description

Black

The upper left quadrant displays black

Bkgd A*

The upper left quadrant displays the Bkgd A
source

Bkgd B

The upper left quadrant displays the Bkgd B
source

Bkgd C

The upper left quadrant displays the Bkgd C
source

Upper Left

Bkgd D

The upper left quadrant displays the Bkgd D
source

Upper Right

Same parameters as above. The default setting is Bkgd B.

Lower Left

Same parameters as above. The default setting is Bkgd C.

Video/Label -

Quadrant
Selection

Lower Right

Same parameters as above. The default setting is Bkgd D.

Bkgd A

Bkgd A*

Bkgd B

Bkgd B*

Bkgd C

Bkgd C*

Video/Label -
Source Label

Bkgd D

Bkgd D*

Enter text in this field to configure the label for
the specified source. Note that a blank field
hides the text overlay in the display quadrant.

Red

0-255

Adjusts the amount of red that is mixed in the
border of the specified source (0 has no
intensity, 255 has full intensity)

Green

0-255

Adjusts the amount of green that is mixed in the
border of the specified source (0 has no
intensity, 255 has full intensity)

Blue

0-255

Adjusts the amount of blue that is mixed in the
border of the specified source (0 has no
intensity, 255 has full intensity)

Color/Border -

Bkgd #

‡‡

Trans

0-100

§§

Adjusts the transparency of the border, around
the specified source, from opaque (0%) to fully
transparent (100%)

‡‡

The default colors for the sources are as follows: BKGD A is set to tan, BKGD B is set to purple, BKGD C is set to cyan,

and BKGD D is set to gray.

§§

The default value is 50.
