9229-QS User Manual •••• (V 1.2) Appendix A. DashBoard Menus •••• 5-5
Configuration Menus
This section briefly summarizes the options and tabs available in the Config tab.
Video Configuration
The following table summarizes the Video tab options available in Dashboard.
Table 5.2 Video Tab Options
Menu Item Parameters Description
Frame 1* The card is using Frame Reference 1
Frame 2 The card is using Frame Reference 2
Reference Input
External
The card is using the reference input on:
• BNC 11 (RM20-9229-C Rear Module)
480i 59.94
720p 59.94
1080i 59.94
576i 50
720p 50
1080i 50
1080PsF 24
Reference
Setup
Output Format
1080PsF 23.98
Specifies the format of the output signal of the
card
Quad Split*
Output 1 displays the Quad Split as configured
using the options in the Quad Split tab
Bkgd A Output 1 displays the Bkgd A source
Bkgd B Output 1 displays the Bkgd B source
Bkgd C Output 1 displays the Bkgd C source
Output Setup
Output 1
Bkgd D Output 1 displays the Bkgd D source
Output 2 Same parameters as above. The default setting is Quad Split.
Output 3 Same parameters as above. The default setting is Bkgd A.
Output 4 Same parameters as above. The default setting is Bkgd B.
Disabled* Dithering is disabled
Output Setup
Dithering
Enabled - low Dithering is enabled and set to 2bits
