5-10 •••• Appendix A. DashBoard Menus 9229-QS User Manual •••• (V 1.2)
Proc Amps Menus
The following table summarizes the Proc Amps tab options available in DashBoard.
Table 5.7 Proc Amps Menu Items
Menu Item Parameters Description
Check box is selected
Enables the adjustment of Proc Amp settings for
the selected output
Enable
Check box is unselected*
The Proc Amp settings for the selected output
are inactive
Video Gain (%) 0 to 200 ‡
Adjusts the Chroma and Luma Gain values
simultaneously
Chroma Gain (%) 0 to 200
§
Adjusts the Cr and Cb values of the output video
signals:
• Increasing the gain increases the saturation of
colors
• Decreasing the gain desaturates the colors
until the signal is black and white
CB Gain (%) 0 to 200
**
Adjusts the Cb component of the chrominance
video signal:
• Increasing the value causes the video signal
colors to become increasingly saturated with
blue
• Decreasing the value desaturates blue from
the video signal
Black Offset (IRE) -8 to 100 ††
Selects how much of the input video signal
values are mapped to black in the output signal:
• Increasing the value increases the black level
and lightens the image
• Decreasing the value darkens the image
Out #
Procamp Reset
Resets the Proc Amp menu settings for the
selected output to the default values
‡
The default value is 100.
§
The default value is 100.
** The default value is 100.
†† The default value is 0.
