Configuration – Cobalt Digital COMPASS 9229-QS Quad-Split Video Processor User Manual
Page 25
9229-QS User Manual
••••
(V 1.2)
Configuration
••••
3-1
Configuration
In This Chapter
This chapter provides instructions for configuring the 9229-QS using the options available in the
DashBoard Control System™.
The following topics are discussed:
•
Video Format and Reference Configuration
•
Video Input and Output Configuration
•
Ethernet Communication Setup
•
GPI Communication Setup
•
Loading the Factory Defaults
•
Software Upgrades
Note
— Before proceeding, ensure that you are running DashBoard software version
2.3.0 or higher. The DashBoard Control System software and user manual are available
to download from the Ross Video website.
