5-2 •••• Appendix A. DashBoard Menus 9229-QS User Manual •••• (V 1.2)
Status Tabs
The following table summarizes the read-only information displayed in the Status tabs.
Table 5.1 Status Menu Functions
Tab Title Item Parameters Description
Product 9229-QS
Supplier Cobalt Digital Inc.
Board Rev ##
Serial Number ###########
Software Rev #.# build ### Indicates the software and build versions
Product (Read-
only)
Firmware Rev ##.## Indicates the FPGA version number
Voltage (V) # Supply Voltage, in Volts
Current (A) # Current consumption of card in Amperes
Power (W) # Power consumption of card in Watts
Rear Module # Indicates the type of Rear Module in the slot
FPGA Core Temp ##C
*
/ ##F FPGA core temperature
CPU Headroom x.xx / y.yy / z.zz † CPU Load average
RAM Available ## / ## MB Memory Used / Total Memory
#.## of 2.0 GB used
Displays the amount of memory used on the
CompactFlash card
Missing CompactFlash card is not present
CF Card Status
Unreadable
An error has occurred, such as incompatible
CompactFlash card, or an error reading the card
Hardware
(Read-only)
Playout RAM x / y / z MB
Displays RAM memory usage where:
• x represents the memory in use
• y represents the memory cache from
previously loaded files
• z represents the total playout memory
Signal
(Read-only)
Reference Status Green - OK Valid reference signal
*
A warning is displayed in DashBoard when the FPGA Core Temperature reaches 85°C. If the temperature reaches 110°C,
the card will automatically shut down to avoid permanent damage and will have to be reset, rebooted, or power cycled
to resume normal operation.
† The CPU Load average is displayed in the following format where x.xx represents in the last minute, y.yy represents the
last five minutes and z.zz is the last fifteen minutes.
