Copy configuration data from a data memory module to an
instrument:
Information:
T
he adjustment must be unlocked. See also chapter "Lock/Unlock
adjustment".
1 S eparate instrument from voltage supply
2 P lug the data memory module into the electronics module.
C onfiguration data of a different instrument are saved in the data
memory module.
3 C onnect instrument again to voltage supply
4 P
ush "E" and "+" keys (at least 3 seconds) until the LED on the
electronics module lights
5 W ait approx. 20 seconds. All parameters except DEVICE SERIAL
NO., DEVICE DESIGN., CUST. TAG NUMBER, LONG TAG
NUMBER, DESCRIPTION, BUS ADDRESS
and the parameters of
the group POSITION ADJUSTMENT and PROCESS CONNEC-
TION
are loaded from the data memory module in the instrument.
T he instrument carries out a restart.
6 B efore you remove the data memory module from the electronics
module, you have to separate the instrument from the voltage
supply
Copy configuration data from one instrument into a data memory
module:
Information:
T
he adjustment must be unlocked. See also chapter "Lock/Unlock
adjustment".
1 S eparate instrument from voltage supply
2 P lug data memory module into the electronics module
3 C onnect instrument again to voltage supply
4 T
he selection for the parameter DOWNLOAD SELECT does not
influence an upload from the instrument in HistoROM (menu
path:"Group selection - Operating menu - Operating"
5 S elect via the parameter HistoROM CONTROL the option
" Instrument - HistoROM" for the transmission direction (menu
path: "Group selection - Operating menu - Operating").
6 W ait approx. 20 seconds. Configuration data are loaded from the
instrument to the data memory module. The instrument does not
carry out a restart.
7 S eparate instrument again from voltage supply
8 R
emove memory module
9 C onnect instrument again to voltage supply
Copy configuration data from a data memory module to an
instrument:
Local adjustment
through local indication
(optional) or remote ad-
justment
